CM 3500 Attic and Wall Spray Insulation Machine

CM 3500 Attic and Wall Spray Insulation Machine

production-3500

Expand your opportunity as a insulation Contractor:

NEWLY UPDATED: CM-3500XL system operates on jobsite power with no costly fuel and generator maintenance. Enhancing better quality, more production capacity and with sustainable recycling methods.

If you want to expand your business in bigger scale with affordable wall spray system then CM-300 is the one you should consider. It is the smallest yet powerful machine in current lineup that gives you economical wall spray system incorporating ‘integrated recycle technology’. While larger truck system come with more costing; this small giant with VP-300 vac-pack all together deliver a combined solution for cost cutting on bigger production capacity. Start it once with a single power line and operate all day long without any additional fuel or maintenance. It is a one stop solution for contractors.

CM3500XL: Training & Testimonial

This CM3500XL (without hopper extension) is powered by a Kubota Diesel generator. Not very loud, either. This video is a testimonial on our training and machine performance.

On-Site Training: Phoenix Arizona

This is a CM3500 with Vacuum Hood set-up. Utilizing a standard vacuum, this CM3500 has a special designed vacuum hood to receive the recycled material back into the divided hopper.

CM3500 with VacPack Recovery

We trained Michigan Premier Builders, in Gaylord, Michigan on the CM3500 vac-pack wall spray unit. Here is a video of our visit.

Why contractors should choose the CM-3500?

Recyclable moisture controlling:

Moisture is always a problem while maintaining insulation wall spray system. CM-300 keeps this to a minimum. In fact, the Coll Machine brand will reduce water needs up to 50%.

Introducing Vac-Pack technology for low maintenance and better efficiency:

gallery-300Most of the machines running on current industry standard follows two backdated methods for recovery and use of recycle fiber. To recycle fiber back to the dusty truck trailer gas powered centrifugal is used which comes with high maintenance cost. It is also time consuming. It also slows down the production rate with pressurized recycle hopper while inherent of fiber flow and air surging problems occurred. Setting up and hauling recycle with buckets back to a manually loaded machine inside of multiple level structures is both time consuming and a dangerous liability risk when handling heavy equipment.

CM-3500 provides an efficient and fast solution. Our Vac Pack technology offers a low maintenance positive pressure vacuum system with no slow down in production by discharging neutral pressure hopper inside with no resulting air surges or dust. It increases endurance of the system with air bypass technology with exclusive air separator which keeps the distance of recycle fiber form contact with the blower. The filter system needs services once a day to insure high efficiency in most cases at the end of the day. CM-3500 also offers a fast, smooth reliable spraying system to meet-up minimizing setup time and maximizing production.

Other benefits:

CM-3500 comes with various benefits for contractors. Few featured points are include below:

  • Simplicity is the key of this machine.
  • Easy to setup and repair. Repairing was never been so quick
  • High production rate
  • No slow down on maintenance.
  • Recycling at its best
  • Easy to transport. CM-3500 can be transported in a truck or trailer to the job side and set-up within minutes with minimum efforts.
  • Saves fuel costs with added features.
  • Self contained  heated water system with water tank and 17.5kw gas generator.
cm3500 auger system
Dual augers with dual hopper system shown



Included options to choose

CM-3500 (Four blower system):

Be economical productive yet cost effective. It is a choice that meets most contractors’ needs. Easy to replace with few hundred dollars and has a service life of approximately 500 to 750 hours.

CM-3500 (Positive displacement blower):

Reduce generator size with high endurance and positive pressure system gives you long lasting offers for contractors. Moreover with recycle stabilized attic spray and open blow application; it gives you extended range of the blowing hose achieving higher production rate.

Technical Specifications

  • Production Rate: Open blow 120 bags/hour
  • Dimensions: 92 Long x 22 Wide x 78 High
  • Weight: 4 Blower w/vac pack 1450 lbs P.D.blower w/ vac pack 1750 lbs
  • Hopper Capacity: Dry hopper w/ extension 4 bags Recycle hopper 1 bag
  • Required power: SI 40 amps 240 volt single phase
  • Generator Size: 15kw (minimum)

System Components

  • CM-3500 (4-blower) Includes machine with ‘integrated recycle hopper and 150 remote cord. OR
  • CM-3500 (P.D. blower) Includes machine with soft start P.D. blower with integrated recycle hopper and 150 remote cord.
  • (Optional) Hopper extension for dry hopper (additional 2 bag capacity).
  • Water Tank Assembly
  • 250 gallon polypropylene insulated/heated double bladder tank assembly for all-weather use
  • Heavy duty pressure hose (170 x 1/4dia) w/quick-connect fittings and convenient hose reel
  • Heavy duty pump and motor assembly (w/run dry capabilities) quick-connect fittings for easy removal and service deluxe 80 mesh filter and fluid level gauge.
  • Duplex outlets for pump and on/off control of internal wetting system.
  • Dimensions: 24W x 116L x 40H (w/o hose reels) 78″ H with hose reels.
  • Empty weight: 850 lbs.
  • Full water weight: 2800 lbs.

CM 3500XL Production Rates

Material: Different materials may produce varying results.
Lbs p/hour: Based on industry-wide standards of 100' hose with 12' rise
Bags p/hr: Standard bags (lbs noted by material)
Sq Ft p/hour: Based on R-19 depth
MaterialLbs p/hrBags p/hrSq ft p/hr
Cellulose (22 lb bag)4500204
Fiberglass (32 lb bag)180056
Rockwool (30 lb bag)220073
Wall Spray Cellulose40 bags/hour

CM 3500XL with Upgraded 24" Airlock Production Rates

Material: Different materials may produce varying results.
Lbs p/hour: Based on industry-wide standards of 100' hose with 12' rise
Bags p/hr: Standard bags (lbs noted by material)
Sq Ft p/hour: Based on R-19 depth
MaterialLbs p/hrBags p/hrSq ft p/hr
Cellulose (22 lb bag)5400245
Fiberglass (32 lb bag)240075
Rockwool (30 lb bag)270090
Wall Spray Cellulose40 bags/hour

CM 3500XL Production Rates Upgraded Airlock with Optional 15 hp PD Blower

Material: Different materials may produce varying results.
Lbs p/hour: Based on industry-wide standards of 100' hose with 12' rise
Bags p/hr: Standard bags (lbs noted by material)
Sq Ft p/hour: Based on R-19 depth
MaterialLbs p/hrBags p/hrSq ft p/hr
Cellulose (22 lb bag)675030612,312
Fiberglass (32 lb bag)3000949,360
Rockwool (30 lb bag)84702823,402

Generator

  • 17.5 kW (Guardian) generator with transfer panel for switching to jobsite power, wood panel enclosure w/ service access louvered door, slide-out bracket (enclosure reduces fiber contamination to generator).
  • Jobsite Power: (optional)150 ft. 63 power cable can be easily connected by qualified electrician. Con serve gas and generator maintenance. Run all day for no fuel costs.

Accessories

Includes 150ft. 3 blowing hose with 12ft. light-weight flexible spray hose 2 1/2 aluminum wall spray nozzle 2 jet 150 ft. x 3 vacuum hose connector tubes w/3 aluminum vacuum wand Cool Tool wall scrubber.
